Otto Bock A200 - Appendices; 13.1 Train Transport Thresholds; 13.2 Required Tools; 13.3 Screw Connection Torques

Corrosion protection
Corrosion protection Dip-coated frame (KTL coating)
13 Appendices
13.1 Threshold values for wheelchairs transportable by train
INFORMATION
► The products in this series fully satisfy the minimum technical requirements of regulation (EU) No.1300/2014
regarding train accessibility for people with disabilities. However, not all versions can comply with all
threshold values due to different settings.
► With the help of the table that follows, you or the qualified personnel can take measurements and verify wheth
er the specific product in question meets the threshold values.
Feature Threshold value (according to regulation (EU) No.1300/2014)
Length 1200 mm (47.2"); plus 50 mm (2") for the feet
Width 700 mm (27.6"); plus 50 mm (2") on each side for the hands when
moving
Smallest wheels approx. 3" or greater according to the regulation, the smallest wheel
must be able to accommodate a gap measuring 75mm (3") horizont
ally and 50mm (2") vertically
Height max. 1375 mm (54.1"); including a 1.84m (72.5") large male wheel
chair user (95th percentile)
Turning radius 1500 mm (59.1")
Maximum weight 300 kg (661 lbs); for wheelchair with occupant, including baggage
Maximum obstacle height that can be
overcome
50 mm (2")
Ground clearance 60mm (2.4"); at an upward slope angle of 10°, ground clearance
must measure at least 60mm (2.4") under the foot rest for going for
ward at the end of the slope
Maximum inclination angle on which the
wheelchair will remain stable
6° (dynamic stability in all directions)
9° (static stability in all directions, also when wheel lock engaged)
13.2 Required tools
The following tools are required for adjustments and maintenance work:
• Allen keys in sizes 2 – 8 mm
• Ring and open-ended spanners in sizes8–24
• Socket wrenches in sizes 8 – 20 mm
• Phillips head screwdriver (size: 2)
• Torque wrench (measurement range 5-50 Nm)
13.3 Torque values of the screw connections
Unless otherwise specified, screw connections are tightened with the following torque values:
• Thread diameter M4: 3Nm
• Thread diameter M5: 5Nm
• Thread diameter M6: 10Nm
• Thread diameter M8: 25Nm
13.4 Sound emission information
INFORMATION
► The products in the series were tested for compliance with maximum sound emission requirements according
to the ISO 7176-14 standard.
► They fully meet the requirements according to the areas of application identified below.
Area of application Maximum sound pressure level
1)
In enclosed rooms 65 db(A)
58
Appendices
A200
