Otto Bock A200 - Electrical System & Control Device Specs; Driving Data; Environmental Conditions

Dimensions and weights
Tyre pressure*** 12" drive wheel: 3.5 bar/350 kPa/50 PSI
* Depending on installed options
** = 3-point turn by 180°
*** Adjust the tyre pressure according to the specifications on the tyre sidewall to prevent injuries or damage to the
product.
Electrical system*
IP protection rating (according to DIN EN
60529)
IPX4
Operating voltage 24V
Batteries 2 x 12V; 28Ah(C5) / 33Ah (C20); AGM; maintenance-free
Lighting:
1 x LED headlight with twilight sensor 24V, maintenance-free
Fuse 60 A in each battery pack
Battery charger For more information, see the included battery charger instructions for
use
* The product meets all requirements under ISO 7176-14.
Control device
Model
IP protection rating (according to DIN EN
60529)
Operating voltage
Max. output current per motor
Force for operating the joystick on the
standard control panel
VR2 (controller and control panel)
IP54
24 V DC
60A
1.6 N
Driving data
Speed* 6km/h (3.7mph)
Climbing ability (basic model)** 7°(12%)
Dynamic stability – uphill*** 7°(12%)
Static stability – uphill/downhill 9°(15.8%)
Static stability – sideways 9°(15.8%)
Maximum obstacle height 15mm (0.6")
Driving distance range (on level sur
faces)****
Approx. 15km (9.3miles)
Braking distance (according to DIN EN
12184:2009)*****
At 6km/h (3.7mph): 1,000mm (39.4") – on level surfaces
* The specified speed can vary by ±10%.
** The control device and the motors must be protected against overloading. Therefore, the continuous climbing
ability depends on the overall weight (wheelchair weight + user weight + load), as well as the ground conditions,
exterior temperature, battery voltage and driving style of the user. In individual cases, the continuous climbing abil
ity may be significantly lower than the specified climbing ability.
*** Approved climbing ability with lowered seat functions, upright back support and lowered leg supports.
**** The specified driving distance range was determined under defined conditions according to ISO 7176-4. In
practice, the driving distance range can be reduced by up to50percent. For information on this, see the section
"Driving distance range" in the instructions for use (user).
***** The braking distance can be correspondingly longer due to user weight, installed options and condition of the
tyres as well as weather and surface conditions.
Allowable environmental conditions
Operating temperature -15°C to +40°C (+5°F to +104°F)
Transport and storage temperature -15°C to +40°C (+5°F to +104°F)
Relative humidity 45%to85%; non-condensing
Corrosion protection
57A200
Technical data
