Ottobock | 25B600
Joystick
The speed and driving direction are controlled with the joy
stick. When a seat option is activated, the joystick operates
this seat option.
[On/Off] Button
Holding this button turns the power wheelchair on or off and
activates/deactivates the drive-away lock.
[Mode] Button
Pressing the button briefly increases/decreases the speed
level. After reaching the maximum speed level, you can
change back to speed level 1 by pressing the button again
(1-2-3-4-5-1-…).
Holding the button (for at least 2 seconds) switches the con
trol unit into the Power Seat Functions menu.
[Warning Flasher On/Off] Button
All 4 warning flashers are activated/deactivated when this
button is pressed.
[Horn] Button
The horn will sound as long as the button is pressed.
[Direction Indicator Left] and [Direction Indicator Right]
Button
Pressing these buttons activates/deactivates the respective
front and rear direction indicators. The direction indicator
lights turn off automatically after 20 seconds.
[Lights On/Off] Button
The front and rear lights are activated/deactivated by press
ing the button.
LCD Display
The LCD display is the communication interface between
the user and the control unit. It indicates the selected speed
level, the remaining battery capacity, the status of power
options as well as warnings and errors. All display symbols
are displayed while the power wheelchair turns on.
Usage
