92 | Ottobock B600
Dimensions and weights
Transport weights* See weight when empty*, of which:
Side panel: < 1kg
Footrest (standard): approx. 1kg
Footrest (manually elevating): 1.8kg
Max. load capacity (user weight)** Base model: 140kg (with optional 40cm electric seat height adjustment:
130 kg)
Model with reinforced chassis: 180kg (with optional 30 cm electric seat
height adjustment: 180 kg)
Model with standard seat, junior option: 100 kg
Turning radius 900 mm
Turning circle*** 1550mm
Caster wheel tyre size 9" – 10"
Drive (rear) wheel tyre size 14"
Tyre pressure See tyre sidewall
* The specified weights vary according to the selected options and model.
** For further limitations pertaining to maximum load capacity, please refer to the order form.
*** = 3-point turn by 180°
Electrical system*
IP protection rating (according to DIN EN
60529)
IPX4
Operating voltage 24V
Appendices
