Otto Bock B600 - Page 93

Ottobock | 93B600
Electrical system*
Batteries:
Gel (standard)
AGM (optional)
2 x 12V; 63Ah(C5)
2 x 12V; 63Ah(C5)
Lighting:
Front LED light
Front direction indicator
Rear LED light (including rear direction indic
ator)
24V, maintenance-free
10W, 24V
24V, maintenance-free
Fuse 120A
Battery charger For more information see the included battery charger instructions for use.
* The product meets all requirements under ISO 7176-14.
Control unit
Model
Operating voltage
Max. output current per motor
enAble50
24 V DC
130 A
Driving data
Speed 6 km/h or 10 km/h (see nameplate for precise information)
Maximum safe inclination Climbing ability, basic model*: 9.5° (17%)
Approved climbing ability with lowered seat height adjustment feature/seat
tilt: max. 6° (10%)
Maximum obstacle height 50 mm (100mm with curb climbing assist)
Range (on level surfaces)** approx. 35 km
Appendices
