5.2 Electric pre-setting
• Single-phase supply + ground 110-240 V∼ ±10%
• Frequency 50 – 60 Hz
• Max absorbed current during emission 5.2 A rms impulsive @ 115 V∼
2.5 A rms impulsive @ 230 V∼
• Apparent line resistance 0.4 Ω @ 99-132 V∼
0.8 Ω @ 198-264 V∼.
NOTE:
The device is intended for permanent installation.
It is forbidden to connect the system by a plug in a wall socket for
safety reasons.
Mobile version has to be requested on order and it is not possible to
transform wall mounted version into a mobile version in field.
NOTE:
A circuit breaker with overcurrent protection must be connected to the
intraoral X-ray equipment with the following features:
–
Nominal current: 10A
–
Differential sensitivity: 0.03A.
Section of line cables must be not lower than 1.5 mm².
Grounding of the system must meet requirement of the laws; a bad
grounding can be dangerous for the operator and can generate
malfunctioning of the device.
NOTE:
The mobile stand is supplied without the mains plug to permit the free
connection at every socket.
Is in charge to the installer supply a mains plug compatible with the
local electrical network with follow features: connection 2P+Earth
protection, minimum working voltage compliant with the power
supply in use, minimum rated current 10A.
Then install the mains plug on the cable by connecting the Y/G wire in
the earth protection connector and the others conductors in the others
free connectors.
The mains plug must be in compliance with the laws and directive in
force of the Country of use and report at least one quality/safety
mark released by a recognized Notified Body.
NOTE:
Ow-RX can be connected to signaling devices outside the installation
room; please make reference to chapter 6.4.1.
It is also possible to mount the system with remote keyboard: in
this case it is necessary to use a RJ45 cable provided by the
Manufacturer.
