6.4.4 Remote Timer configuration
NOTE:
The mains power supply has to be provided only on wall support
side.
NOTE:
The connection cable between wall support and remote timer
supplied in the Remote Timer kit (code 6659300700) is 20 meters
long, ending with RJ45 connector.
The maximum distance between wall support and timer must not
exceed the cable length.
6.4.4.1 Wall support set-up
For the Remote Timer wall support set-up follow the instruction listed in
paragraph 6.1.1 – Timer set-up (standard configuration).
