6.4.2 Remote X-ray button
NOTE:
Whatever remote X-ray button installation is implemented, the front
panel of the timer must be visible from the remote button location to
allow the user to see technical factors before starting an exposure.
There are two possible alternative for remote X-ray button:
1. A door bell X-ray button (not provided) can be installed following the
instruction here below.
NOTE:
The connecting cable between Timer and Remote X-ray button, passing
into the wall or external, must always be put into a metal conduct to
avoid any kind of disturbance to the signals passing through the cable.
The cable can be a maximum of 15 meters long and consequently the
distance between Timer and X-ray button must be shorter than this
length.
The connecting cable must have a 1mm
2
minimum section and must
be connected to the X6.1 and X6.2 connectors on the CPU board A2
(see chapter 12).
The remote X-ray button can be connected in parallel to the standard
X-ray button supplied with the timer, using the same connectors.
Safety regulations stipulate that a button enabled by an appropriate
safety key must be used.
2. The kit P/N 6659120000 provides a way to install remotely the X-ray
button supplied with the timer.
The kit includes a wall support plate with a terminal strip.
NOTE:
The connecting cable between Timer and remote X-ray button (not
provided) must have a 1mm
2
minimum section.
The connecting cable must always be put inside a metal conduct to avoid
any disturbance to the signals passing through the cable.
