2.1.2 Electromagnetic immunity
In accordance with the IEC 60601-1-2 standard, Ow-RX is suitable for
use in the electromagnetic environment described below.
The customer or user of the system must ensure that it is used in the
said environment.
Immunity test
Test level
IEC 60601-1-2
Compliance level
EMC environment
of use
Electrostatic
discharges (ESD)
IEC 61000-4-2
± 6 kV contact
± 8 kV in air
± 6 kV contact
± 8 kV in air
The flooring must be
must be wood, concrete
or ceramic tile. If the
flooring is covered with
synthetic material, the
relative humidity must
be at least 30%.
Transients/sequence
of rapid electric
impulses
IEC 61000-4-4
± 2 kV for power
supply lines
± 1 kV for
input/output lines
± 2 kV for power
supply lines
± 1 kV for
input/output lines
The quality of the mains
voltage must be the
same as a typical
commercial or hospital
environment.
Overvoltages
IEC 61000-4-5
± 1 kV between
phases
± 2 kV between
phase and earth
± 1 kV between
phases
± 2 kV between
phase and earth
The quality of the mains
voltage must be the
same as a typical
commercial or hospital
environment.
Voltage dips, short
breaks and voltage
variations of the
power supply feed
line IEC 61000-4-11
0 % U
t
for 0.5 cycles
40 % U
t
for 5 cycles
70 % U
t
for 25 cycles
0 % U
t
for 5 s
0 % U
t
for 0.5 cycles
40 % U
t
for 5 cycles
70 % U
t
for 25 cycles
0 % U
t
for 5 s
The quality of the mains
voltage must be the
same as a typical
commercial or hospital
environment. If the
Ow-RX user requires
continuous operation
during interruptions in
the mains voltage, it is
recommended to power
the Ow-RX with an
uninterrupted power
supply or batteries.
Magnetic field at the
main frequency
(50/60 Hz)
IEC 61000-4-8
3 A/m 3 A/m The levels of the
magnetic fields at mains
frequency must be the
same as a typical
commercial or hospital
environment.
Note: U
t
is the a.c. mains voltage prior to the application of the test level.
