6.5 Electrical connection
6.5.1 Electrical connection for standard and mobile stand
versions
NOTE:
Cables coming from the tubehead are supplied for the 80 cm
extension arm.
For the 30 cm and 60 cm extension arm and for mobile stand
version, the surplus part of the cables must be positioned to the top
of the timer with a suitable loop, without passing over the Driver
board area. Fix the cables with the provided strip.
1. Connect the power cables from the tubehead to the Driver board
wiring the cables to the connector X4 (OUTPUT) and shield to screw
W2, following the positions as in the table:
Tubehead wires
colour
Tubehead wires
identification
Driver board
Green 1 X4.1
Brown 2 X4.2
White 3 X4.3
Yellow/Green Ground X4.GND
Black Shield Screw W2
2. Connect the signal cable of the tubehead to the Driver board wiring
the cables to the connector X2 (HEATER) following the position as in
the table:
Tubehead wires
colour
Tubehead wires
identification
Driver board
X2 terminal
White/Yellow + +
Green/Brown - -
3. Make the connection between the general switch and the terminal
strip of the timer using a bipolar cable plus ground, section 1.5 mm
2
(16 AWG). Fix the cable to the terminal strip following the positions
as shown (L = line, N = neutral, Ground = yellow/green cable). The
conductors have to be secured to the timer base.
4. Assemble the two pins lock (1 - Figure 6-19) on the timer cover; these
pins (code 2100511300) are included in the mounting hardware
packaging.
