6.4.3.3 Wireless X-ray button – Timer matching
NOTE:
This procedure has to be performed in case of wireless X-ray button
replacement or in case of matching lost.
To match wireless X-ray button and timer, proceed as follow:
1. Remove the plastic timer cover (see paragraph 6.1.1 –
point 3) without disconnect the cables between timer and
cover.
2. Switch on the equipment and verify that it is into ready
mode.
3. Press and release the button on the A6 Radio board
(Figure 6-17). The relevant LED will turn on.
4. Press and hold pressed the wireless X-ray button until the
green LED switches on (about 10 seconds).
5. For 10 seconds the green LED of the X-ray button flashes
(1 flash for second). During this time press and release the
wireless X-ray button: the green LED blinks slowly for ten
times. If the LED blinks quickly, the matching failed;
switch off the equipment and repeat the procedure from
point 2.
6. If you wait more than 10 seconds, the LED flashes ten
time quickly, and you have to repeat the procedure from
point 4.
