6.3 Assembling the arms
6.3.1 Assembling the extension arm
1. Insert the extension arm into the arm support block which is an
integral part of the wall support plate.
NOTE:
You must keep the arm orthogonal to the plate to be able to insert the
shaft into the bush placed inside the support.
2. Assemble the extension arm frictioning mechanism block (1 – Figure
6-4); this frictioning mechanism (code 6159300100) is included in
the mounting hardware packaging.
3. Assemble the arm rotation stop screw (2 - Figure 6-4) in the hole
present on the shaft; this screw (code 2100014800) is included in the
mounting hardware packaging.
4. Tighten the two lateral screws (3 - Figure 6-4 – one on each side)
ensuring that they block the arm rotation without interfere with the
extension arm pin.
