Remove the X-ray button from the Timer disconnecting the cable
from X6.1 and X6.2 connectors.
Assemble the button on the wall support plate connecting the cable
on the terminal strip.
The connecting cable between Timer and remote X-ray button must
be connected to X6.1 and X6.2 connectors (Timer side) and to the
terminal strip of the support plate.
The support plate has to be fixed on the wall using the fisher type
screws provided.
