1 – TIMER: Ow-RX
WARNING:
The Driver board and the tubehead are matched in the factory and
therefore MUST be replaced as a couple.
Ref. VSM code Description Note
1 6159300100 Frictioning mechanism assy
2 8459400400 A2 Driver board and Tubehead
assembly
5859301000 A2 CPU board 3
4695463800 A6 Radio board Present only
with wireless
X-ray button
-- 6259300300 Flat cable CPU-Driver board
4 4291420900 ON/OFF switch
6659300900 X-ray push button 5
6659303200 Wireless X-ray push button
6 5459302000 Timer keypad
7 6659301000 Timer front cover complete of
keypad
8 5459302300 Remote timer keypad
9 6659301100 Remote timer front cover complete
of keypad
10 5859301400 A8 / A9 Remote Interconnection
control board
Present only
with Remote
Timer version
11 5859301200 A5 External signal board Optional
F1 2300997200 Fuse 6.3 A T 6.3x32 250V Mounted on
Power PCB
F3 2300997200 Fuse 6.3 A T 6.3x32 250V For mobile
version
4560311800 Fuse holder -
4560311900 Cap for fuse holder
For mobile
version
