Before making any measurements, connect the probe to the
instrument and connect the ground terminal to the ground.
Vertical System
The vertical system can be used to adjust the vertical scale, the position and
other settings of the channel. Each channel has a separate vertical menu,
which can be set individually for each channel.
Vertical position
Press the CH1/CH2 keys to select the channel, and move the vertical position
of the selected channel up or down by pressing the or direction keys.
Press the and direction keys at the same time to center the vertical
position.
Vertical Volt/Div Setting
The volt/div range is 10mV/div-10V/div (probe 1X), stepping in the 1-2-5 way,
or 100mV/div-100V/div (probe 10X), 1V/div-1000V/div (probe 100X),
10V/div-10000V/div (probe 1000X) , 100V/div-100000V/div (probe 10000X).
Press the CH1/CH2 key to select the channel, and press the or
direction key to change the volts/div setting of the selected channel.
The description of the vertical system setting menu is as follows:
Turn on the waveform display.
Turn off the waveform display.
The normal sampling method uses the AC and DC
components of the input signal.
Block the DC component of the input signal.
Disconnect the input signal.
Choose one of the values according to the probe
attenuation factor to keep the vertical scale
reading accurate.
Limit the bandwidth to 20MHz to reduce display
noise.
To Next Page
