Owon HDS25 - Arbitrary Waveform Generator (Optional)

38
Basic function
Range
Minimum
resolution
Accuracy
Diode test
√(<0-2V)
Auto range
√
TRMS
√
[1] : When measuring AC voltage/current or capacitance, accuracy guarantee
range is 5% to 100% of the range.
Arbitrary Waveform Generator (Optional)
Characteristics
Description
Waveform Frequency
Sine
HDS242(S)
HDS272(S)
HDS2102(S)
HDS2202(S)
0.1Hz～25MHz
HDS25(S)
0.1Hz～10MHz
Square
0.1Hz~5MHz
Ramp
0.1Hz~1MHz
Pulse
0.1Hz~5MHz
EXP
0.1Hz~5MHz
Sampling
125MSa/s
Amplitude(50Ω)
0.01Vpp ~ 2.5Vpp
DC offset(High Z)
±(2.5V – Amplitude Vpp/2)
Frequency Resolution
0.01%
Channel
1
Waveform Depth
8k
Vertical Resolution
14 bit
Output Impedance
50 Ω
