Owon HDS25 - The Automatic Measurement of Voltage Parameters

16
9 types of measurement can be displayed at the bottom left of the screen.
For bandwidth ≤100MHz models, automatic range types include Frequency,
Period, Amplitude, Maximum, Minimum, Peak-to-Peak value, Mean, and
RMS.
For bandwidth 200MHz models, automatic range types include Frequency,
Period, Amplitude, Maximum, Minimum, Peak-to-Peak value, Mean, RMS,
Rise Time, Fall Time, +PulseWidth, -PulseWidth.
The description of the automatic measurement Function Menu is as follows:
Function Menu
Description
Measure
ON
OFF
Turn automatic measurement on
or off.
Source
CH1
CH2
Set the source.
Add
Del
Freq (F) □
Period (T) □
Amp (Va) □
Min (Mi) □
Max (Ma) □
PK - PK (Vpp) □
Mean(V) □
RMS (RMS) □
Rise Time (RT) □
Fall Time (FT) □
+PulseWidth (PW) □
-PulseWidth (NW) □
Add or delete the selected
measurement type (displayed in
the lower left corner, up to 9
types).
Note: The unselected state is □;
The selected state is ■.
The automatic measurement of voltage parameters
The oscilloscopes provide automatic voltage measurements including
Mean, PK-PK, RMS, Max, Min and Vamp. Figure 3- 9 below shows a pulse
with some of the voltage measurement points.
