Save the current parameter settings of the
oscilloscope to the internal memory.
Call the settings saved in the current storage
location.
Reference Waveform
The actual waveform can be compared with the reference waveform to find out
the difference. Press the Save key to enter the save function menu, and press
F2 to select the reference waveform to enter the reference waveform menu.
The description of the Reference Waveform menu is as follows:
Select the reference waveform to be saved.
Call or close the waveform of the current target
address in the internal memory. When it displays
"On", if there is a stored waveform at the current
address, the waveform will be displayed, and the
address number and waveform related
information will be displayed in the upper left
corner; if the current address is not stored, it will
display "Address No.: No waveform saved".
Save the reference waveform of the source to the
memory.
File
The file can be saved as waveform or image. The waveform and image can be
read by plugging and unplugging the USB data cable or selecting MSC in the
USB option on the next page of system settings.
