Characteristics
Description
Probe attenuation
1X 、10X、100X、1000X 、10000X
Maximum input
voltage
400 V (DC + AC ,PK - PK)
Bandwidth limit
20 MH(except HDS25(S)) ,Full bandwidth
Horizontal
Sampling rate range
0.25 Sa/s～250 MSa/s
Waveform
interpolation
(Sinx)/x
Sweep speed range
(S/div)
HDS25(S)
HDS242(S)
HDS272(S)
5ns/div - 1000s/div,Stepping in
the 1-2-5 way
HDS2102(S)
HDS2202(S)
2ns/div - 1000s/div,Stepping in
the 1-2-5 way
Time base accuracy
±100 ppm
Record length
8K or 4K optional
Vertical
Sensitivity
(Volt/div) range
10 mV/div～10 V/div
Displacement range
HDS25(S)
HDS242(S)
HDS272(S)
HDS2102(S)
±6 div
HDS2202(S)
±2 V (10 mV/div – 200 mV/div)；
±100 V (500 mV/div – 10V/div)；
Analog bandwidth
HDS25(S)
25MHz
HDS242(S)
40 MHz
HDS272(S)
70 MHz
HDS2102(S)
100 MHz
HDS2202(S)
200 MHz
Single bandwidth
Full bandwidth
Low frequency
response
(AC coupling, -3dB)
≥10 Hz
Rise time
(typical on BNC)
HDS25(S)
≤ 14 ns
HDS242(S)
≤ 8 ns
HDS272(S)
≤ 5 ns
HDS2102(S)
≤ 3.5 ns
HDS2202(S)
≤ 1.75 ns
