Owon HSA1000 Series User Manual

5.Menu Interpretation
58
Set AF triggering conditions.
⚫[AF Trigger On Off]
Set AF trigger is open or close.
⚫[Edge Neg Pos]
Set positive edge or negative edge.
⚫[Trigger Mode]
Set trigger mode is single trigger or continue trigger.
⚫[Trigger Level]
Set trigger amplitude.
⚫[Trigger Delay]
Set trigger delay time.
⚫[Return]
Return to the upper-level menu.
4) [Date Reset]
Set the data reset of the maximum, minimum, and average values
of the AM modulated signal.
5) [Return]
Return to the upper-level menu.
5.13.3.2 [FM >]
Enter FM demodulation submenu.
1) [Carrier Freq]
Set the carrier frequency of the FM modulation signal.
2) [ IF BW]
Set the demodulation bandwidth .
3)[Setup >]
Set the time axis, depth axis and AF trigger of AM modulation.
a) [Time Axis >]
Set timeline parameters.
⚫[Ref.Value]
Set the start reference time in the timeline.
⚫[Position]
Sets the waveform's reference position in the timeline.
⚫[Scale/Div Auto Man ]
Set each scale automatically or manually.
