RULE SAVED".
4. Under the status of stop, data comparing will stop, and when it goes on
running, the number of Pass/Fail will increase from the former number, not
from zero.
5. When the waveform playback mode is on, Pass/Fail is used to test the
played-back waveform specially.
● Output
Push the Utility button, select Function in the bottom menu, select Output in
the left menu.
Output menu item in the bottom menu sets the output type of Trig Out(P/F)
port on Rear Panel. In the bottom menu, select Output. The description of
Output menu is shown as the follows:
VGA menu item in the bottom menu sets the output of VGA port. Connect the
VGA port to an external monitor or projector. Turn on the VGA port in this
menu, the oscilloscope display can be shown on an external monitor or
projector.
Device and Print Setup menu items set the print output, refer to "How to Print
the Screen Image" on page 99.
● LAN Set
Using the LAN port the oscilloscope can be connected with a computer.
● Update
Use the front-panel USB port to update your instrument firmware using a USB
memory device. Refer to "How to Update your Instrument Firmware" on page
85.
● DAQ
You can use the multimeter data recorder to record the measurements when
measuring current/voltage by multimeter (optional). Refer to "Multimeter
Recorder" on page 113.
