Paccar DAF CF - Page 343

344
13
Emergency repairs
Front fog light and/or cornering light
1. Remove the lower cover in the
stepwell.
2. Lift the connector lock and remove
the connector. See arrow at position
1.
3. Rotate the bulb fitting anti-
clockwise. See arrow at position 2.
4. Pull the bulb fitting out of the
reflector. See arrow at position 3.
5. Replace the bulb.
6. Push the bulb fitting into the
reflector and rotate the holder
clockwise to secure it.
NOTE: Make sure the
bulb fitting clicks into
position.
7. Fit the connector.
8. Install the lower cover in the stepwell.
9. Install the attachment bolts.
Rear lights
LED rear lights are optional.
NOTE: Make sure that the LED rear lights stay clean for optimum visibility.
CAUTION:
– If LED lighting is defective, contact the nearest DAF Service dealer.
You cannot replace defective LED lighting yourself.
1. Remove the four screws and remove the lens cap.
D002210-2
2
1
3
