User’s Manual
20
Highlighting Schedule On and pressing the button toggles On and
Off. When set to On, you can select the day, time range and interval
that you want the DVR to run self-diagnostics on the recorder. The
Interval can be selectable from 1 min. to 7 days or Never. Highlight
the + and press the
button to add a schedule item. The
box allows
you to delete a check recording schedule.
Highlight the Settings box beside Check Alarm-In and press the button. You can select the interval that you want
the DVR to run self-diagnostics on Alarm Inputs. You can select from 1 hr. to 30 days or Never.
Highlight the Settings box beside Disk Almost Full, and press the
button. Select the percentage level of disk usage
at which you want the DVR to trigger an alert. Percentage levels range from 80% to 99%.
Highlight the Settings box beside Disk Bad, and press the
button. Select percentage level of bad disk sectors at
which you want the DVR to trigger an alert. Percentage levels range from 10% to 90%.
Highlight the Settings box beside Disk Temperature, and press the
button. Select the temperature of hard disk
drive at which you want the DVR to trigger an alert if the temperature exceeds the defined threshold. Refer to the hard
disk drive manufacturer’s documentation for the correct temperature setting.
The DVR can be set to react to system events. Highlight the Actions box beside the desired event and press the
button. System events can be associated with an Alarm-Out connector, sound the DVR’s internal buzzer, and/or notify
a number of different devices.
NOTE: Alarm-Out action cannot be set to System and Panic Record events.
For the Notify action to work, the DVR should be registered in the RAS (Remote Administration System).
Recording Setup
General
Highlight General and press the
button, and the General setup screen appears.
Figure 13 : Record – General setup screen.
