GETTING TO KNOW YOUR PRODUCT
Package Contents:
• SK Series Switch
• Power cord
• Rack Mount Set
The front panel of the SK switches has several blue LEDs. See Table1 below for more information.
Table 1: Front panel LED explanation from left to right.
LED
Status
Operation
POWER
Blue
The switch is powered on
Off
The switch is turned off
Off No PoE Compliant device is
connect to port
Ports 1-24 LINK/ACT
Blue
Port is online (link established)
Flashing Blue
Activity
Off
No device connected
The rear panel of the SX series switches has several blue LEDs and port connections. See table 2 below
for more information.
Table 2: Rear panel LED and port connection explanation from left to right.
Table 2: Rear Panel LED and Port Connection Explanation from Left to Right
