Panasonic Diga DMR-EZ49V User Manual

72
VQT2J52
Additional connections
Connecting a television and VCR
Connecting a television and VCR or digital satellite receiver
“AV2 Input” setting in the Setup menu (> 66)
Connect the unit directly to the television (> 8, [B])
AC IN
RF
RF
IN
IN
RF
RF
OUT
OUT
OPTICAL
DIGITAL AUDIO OUT
(PCM/BITSTREAM) OUT
VIDEO
AV1 (TV)
R- AUDIO-L
AV2 (EXT)
VHF/UHF
RF IN
AV
AV
RF OUT
VHF/UHF
RF IN
1
4
2
6
5
3
To the aerial
Aerial cable
Cooling fan
RF coaxial
cable
This unit’s rear panel
To household mains socket
(AC 220 to 240 V, 50 Hz)
Television’s rear panel
VCR’s rear panel
AC mains lead
(included)
Connect only after all other
connections are complete.
RF coaxial
cable
(included)
Connecting a terminal
other than the 21-pin
Scart terminal (> 9, 71)
Fully wired 21-pin
Scart cable
21-pin Scart cable
“AV2 Input” setting in the Setup menu (> 66)
Required setting
AC IN
RF
RF
IN
IN
RF
RF
OUT
OUT
OPTICAL
DIGITAL AUDIO OUT
(PCM/BITSTREAM) OUT
VIDEO
AV2 (DECODER/EXT) AV1 (TV)
R- AUDIO-L
AV2 (EXIT)
VHF/UHF
RF IN
AV
AVAVAV
RF OUT
VHF/UHF
RF IN
1
5
6
3
4
2
7
Digital satellite receiver’s rear panel
To the aerial
To household mains socket
(AC 220 to 240 V, 50 Hz)
Fully wired 21-pin
Scart cable
AC mains lead
(included)
Connect only after all other
connections are complete.
21-pin Scart
cable
RF coaxial cable
(included)
Cooling fan
Connecting a terminal other
than the 21-pin Scart
terminal (> 9, 71)
VCR’s rear
panel
Aerial cable
RF coaxial
cable
21-pin Scart cable
Television’s rear panel
This unit’s rear panel
Required setting
DMR-EZ49VEGEC-VQT2J52_eng.book 72 ページ ２０１０年１月７日 木曜日 午後４時０分

Panasonic Diga DMR-EZ49V Specifications

General

Category	DVD Recorder
Brand	Panasonic
Model	DMR-EZ49V
DVD Formats	DVD-RAM, DVD-R, DVD-RW, DVD+R, DVD+RW
VHS Playback	Yes
HDMI Output	Yes
USB Port	Yes
Audio Recording System	Dolby Digital
Playback Media	DVD-Video, DVD-RAM, DVD-R, DVD-RW, DVD+R, DVD+RW, CD, CD-R, CD-RW, VHS
Hard Drive	No
Component Video Output	Yes
Composite Video Output	Yes
S-Video Output	Yes
Analog Audio Output	Yes
Recording Modes	XP, SP, LP, EP
Video Recording System	PAL
Audio D/A Converter	192 kHz/24-bit
Connectivity	HDMI, Component, Composite, S-Video, USB
Digital Audio Output	Coaxial
