Panasonic FP-X0 L30R - Page 264

Num-
ber
Name Boo-lean
Operand
Description
Steps
FP0/FP-e
FP0R
FP
Σ
FP-X
FP-X0
FP2
FP2SH/FP10SH
High speed counter/Pulse output instruction for FPΣ/FP-X
F0
High-speed
counter and
Pulse output
controls
MV
S, DT90052
Performs high-speed counter
and Pulse output controls
according to the control code
specified by “S”. The control
code is stored in DT90052.
5
- -
- - -
F1
Change and read
of the elapsed
value of high-
speed counter
and Pulse output
DMV
FP
Σ
:
S, DT90044
FP-X:
S, DT90300
Transfers (S+1, S) to high-speed
counter and Pulse output
elapsed value area (DT90045,
DT90044).
7
- -
- - -
FPΣ:
DT90044, D
FP-X:
DT90300, D
Transfers value in high-speed
counter and Pulse output
elapsed value area (DT90045,
DT90044) to (D+1, D).
7 - - - - -
F166
Target value
much on
HC1S
n, S, D
Turns output Yn on when the
elapsed value of the built-in high-
speed counter reaches the target
value of (S+1, S).
11
- -
- - -
F167
Target value
much off
HC1R
n, S, D
Turns output Yn off when the
elapsed value of the built-in high-
speed counter reaches the target
value of (S+1, S).
11
- -
- - -
F171
Pulse output
(Trapezoidal
control and home
return)
SPDH
S, n
Positioning pulses are output
from the specified channel, in
accordance with the contents of
the data table that starts with S.
5
- -
- - -
F172
Pulse output
(JOG operation)
PLSH
S, n
Pulse strings are output from the
specified output, in accordance
with the contents of the data
table that starts with S.
5 - - - - -
F173
PWM output
PWMH
S, n
PWM output is output from the
specified output, in accordance
with the contents of the data
table that starts with S.
5 - -
- - -
F174
Pulse output
(Selectable data
table control
operation )
SP0H
S, n
Outputs the pulses from the
specified channel according to
the data table specified by S.
5
- -
- - -
F175 Pulse output
(Linear
interpolation)
SPSH S, n
Pulses are output from channel,
in accordance with the
designated data table, so that
the path to the target position
forms a straight line.
5
- -
*2
- - -
F176 Pulse output
(Circular
interpolation)
SPCH S, n
Pulses are output from channel,
in accordance with the
designated data table, so that
the path to the target position
forms an arc.
5
- -
*2
- - -
: Available, : Not available, : Not available partially
*1) The elapsed value area differs depending on used channels.
*2) This instruction is available for FPΣ C32T2, C28P2, C32T2H and C28P2H.
