Panasonic FP-X0 L30R - Page 263

Num-
ber
Name Boolean
Operand
Description
Steps
FP0/FP-e
FP0R
FP
Σ
FP-X
FP-X0
FP2
FP2SH/FP10SH
F174
Pulse output
(Selectable data
table control
operation )
SP0H
S, n
Outputs the pulses from the
specified channel according to the
data table specified by S.
5
-
- - - -
F175 Pulse output
(Linear
interpolation)
SPSH S, n
Pulses are output from channel,
in accordance with the designated
data table, so that the path to the
target position forms a straight
line.
5
-
- -
*3
- -
F177
Pulse output
(Home return)
HOME
S, n
Performs the home return
according to the specified data
table.
7
-
- - - -
F178 Input pulse
measurement
(No. of pulses,
cycle for input
pulses)
PLSM S1, S2, D Measures the number of pulses
and cycle of pulses to be input to
the high-speed counter of the
specified channel.
5
- - -
*3
- -
*3) Available for FP-X0 L40 and L60 types only.
