Panasonic FP-X0 L30R - Page 266

Num-
ber
Name Boolean
Ope-
rand
Description
Steps
FP0/FP-e
FP0R
FP
Σ
FP-X
FP-X0
FP2
FP2SH/FP10SH
F235
P235
16-bit binary data
→
Gray code
conversion
GRY
PGRY
S, D
Converts the 16-bit binary data of
“S” to gray codes, and the
converted result is stored in the “D”.
6
F236
P236
32-bit binary data
→
Gray code
conversion
DGRY
PDGRY
S, D
Converts the 32-bit binary data of
(S+1, S) to gray code, and the
converted result is stored in the
(D+1, D).
8
F237
P237
16-bit gray code
→
binary data
conversion
GBIN
PGBIN
S, D
Converts the gray codes of “S” to
binary data, and the converted
result is stored in the “D”.
6
F238
P238
32-bit gray code
→
binary data
conversion
DGBIN
PDGBIN
S, D
Converts the gray codes of (S+1, S)
to binary data, and the converted
result is stored in the (D+1, D).
8
F240
P240
Bit line to bit
column
conversion
COLM
PCOLM
S, n, D
The values of bits 0 to 15 of “S” are
stored in bit “n” of (D to DC+15). 8
F241
P241
Bit column to bit
line conversion
LINE
PLINE
S, n, D
The values of bit “n” of (S) to (S+15)
are stored in bits 0 to 15 of “D”.
8
F250
Binary data →
ASCII conversion
BTOA
S1, S2,
n, D
Converts multiple binary data to
multiple ASCII data.
12 *1
F251
ASCII → binary
data conversion
ATOB
S1, S2,
n, D
Converts multiple ASCII data to
multiple binary data.
12 *1
F252
ASCII data check
ACHK
S1, S2,
n
Checks the ASCII data strings to be
used in F251 (ATOB) instruction.
10 *2 *3
Character strings instructions
F257
P257
Comparing
character strings
SCMP
S1, S2
These instructions compare two
specified character strings and
output the judgment results to a
special internal relay.
10
F258
P258
Character string
coupling
SADD
S1, S2,
D
These instructions couple one
character string with another.
12
F259
P259
Number of
characters in a
character string
LEN
S, D
These instructions determine the
number of characters in a character
string.
6
F260
P260
Search for
character string
SSRC
S1, S2,
D
The specified character is searched
in a character string.
10
F261
P261
Retrieving data
from character
strings (right
side)
RIGHT
S1, S2,
D
These instructions retrieve a
specified number of characters from
the right side of the character string.
8
F262
P262
Retrieving data
from character
strings (left side)
LEFT
S1, S2,
D
These instructions retrieve a
specified number of characters from
the left side of the character string.
8
F263
P263
Retrieving a
character string
from a character
string
MIDR
S1, S2,
S3, D
These instructions retrieve a
character string consisting of a
specified number of characters from
the specified position in the
character string.
10
F264
P264
Writing a
character string
to a character
string
MIDW
S1, S2,
D, n
These instructions write a specified
number of characters from a
character string to a specified
position in the character string.
12
F265
P265
Replacing
character strings
SREP
S, D, p,
n
A specified number of characters in
a character string are rewritten,
starting from a specified position in
the character string.
12
: Available, : Not available, : Not available partially
*1) This instruction is available for FPΣ 32k type.
*2) This instruction is available for FPΣ Ver. 3.10 or later.
*3) This instruction is only available for FP-X Ver.2.0 or later.
