Num-
ber
Name Boolean
Ope-
rand
Description
Steps
FP0/FP-e
FP0R
FP
Σ
FP-X
FP-X0
FP2
FP2SH/FP10SH
Integer type data processing instructions
F270
P270
Maximum value
(word data (16-
bit))
MAX
PMAX
S1,
S2, D
Searches the maximum value in the
word data table between the S1and
“S2”, and stores it in the “D”. The
address relative to S1is stored in
D+1”.
8
*1
F271
P271
Maximum value
(double word
data (32-bit))
DMAX
PDMAX
S1,
S2, D
Searches for the maximum value in the
double word data table between the
area selected with S1and “S2”, and
stores it in the “D”. The address relative
to S1is stored in D+2”.
8
*1
F272
P272
Minimum value
(word data (16-
bit))
MIN
PMIN
S1,
S2, D
Searches for the minimum value in the
word data table between the area
selected with S1 and S2, and stores
it in the D”. The address relative to S1
is stored in D+1”.
8
*1
F273
P273
Minimum value
(double word
data (32-bit))
DMIN
PDMIN
S1,
S2, D
Searches for the minimum value in the
double word data table between the
area selected with S1and S2, and
stores it in the “D”. The address relative
to S1is stored in D+2”.
8
*1
F275
P275
Total and mean
values (word
data (16-bit))
MEAN
PMEAN
S1,
S2, D
The total value and the mean value of
the word data with sign from the area
selected with S1 to S2are obtained
and stored in the “D”.
8
*1
F276
P276
Total and mean
values (double
word data (32-
bit))
DMEAN
PDMEAN
S1,
S2, D
The total value and the mean value of
the double word data with sign from the
area selected with S1to S2are
obtained and stored in the “D”.
8
*1
F277
P277
Sort (word data
(16-bit))
SORT
PSORT
S1,
S2, S3
The word data with sign from the area
specified by S1to S2are sorted in
ascending order (the smallest word is
first) or descending order (the largest
word is first).
8
*1
F278
P278
Sort (double
word data (32-
bit))
DSORT
PDSORT
S1,
S2, S3
The double word data with sign from the
area specified by “S1to S2are sorted
in ascending order (the smallest word is
first) or descending order (the largest
word is first).
8
*1
F282
P282
Scaling of
16-bit data
SCAL
PSCAL
S1,
S2, D
The output value Y is found for the input
value X by performing scaling for the
given data table.
8
*1
F283
P283
Scaling of
32-bit data
DSCAL
PDSCAL
S1,
S2, D
The output value Y is found for the input
value X by performing scaling for the
given data table.
10
F284
P284
Inclination
output of 16-bit
data
RAMP S1,
S2,
S3, D
Executes the linear output for the
specified time from the specified initial
value to the target value.
10
*2
*2
Integer type non-linear function instructions
F285
P285
Upper and
lower limit
control
(16-bit data)
LIMT
PLIMT
S1,
S2,
S3, D
When S1>S3, S1D
When S1<S3, S2D
When S1<or = S3<or = S2, S3D
10
*1
: Available, : Not available, : Not available partially
*1) This instruction is only available for FP-e Ver.1.2 or later.
*2) This instruction is only available for FP-X Ver.2.0 or later, and FPΣ Ver. 3.10 or later.
