3. Pull the release lever in the direction of the arrow to disconnect the PSU from the back board.
Release Lever
Back Board
4. Replace the PSU.
Current PSU
New PSU
5. Follow the steps in "Installing the Power Supply Unit".
Installation Manual 105
2.2.9 Installing/Replacing the Power Supply Unit
