Accessories and User-supplied Items
Accessories (included): none
User-supplied (not included): none
Note
To establish a conference call involving 6 to 8 parties, install an EECHO16 card and enable echo
cancellation for conferences using the Maintenance Console. For details, refer to "
Echo Cancel—
Conference" in "4.17 [2-9] System Options" of the PC Programming Manual.
LED Indications
Indication Colour
Description
CARD STATUS Green/Red Card status indication
• OFF: Power Off
• Green ON: Normal (all ports are idle)
• Green Flashing (60 times per minute): Normal (a port is in use)
• Red ON: Fault (includes reset)
• Red Flashing (60 times per minute): Out of Service
Installation Manual 189
2.8.7 EECHO16 Card (KX-TDA6166)
