2.6.4 CID8 Card (KX-TDA0193)
Function
8-port Caller ID
signal type FSK/FSK (with Call Waiting Caller ID [Visual Caller ID])/DTMF. To be mounted on
the ELCOT16 card.
SW1
OFF
ON
ON
OFF
SW2
CID8 Card
inside
Screw
Accessories and User-supplied Items
Accessories (included): Screws ´ 2
User-supplied (not included): none
Switch Settings (on
ELCOT16 card)
Switch Type Usage and Status Definition
Port Setting DIP Keep
all DIP switches at default "ON"
positions. Do
not change the
positions of these switches.
138 Installation Manual
