b. Overlap the CS coverage areas of at least 2 CSs at any location in the installation site.
Channel no. 0 Channel no. 1
Channel no. 2 Channel no. 3
c. Make sure that the radio signal strength level is greater than "3" at any location in the service area
required by the user.
Note
• If a channel
is set, the results of measurement for the 24 slots on the channel are saved each time.
If the same channel is set, the new results override the previous ones. Therefore, a measurement
of 10 channels ´ 24 slots in total can be made.
• If correct results cannot be obtained (e.g., there are many frame errors), change the location of the
CS and repeat the site survey to select the best location.
Referring to the Stored Scan Data
Using the KX-TCA255/KX-TCA256/KX-TCA355
Press 1, 9, and POWER
for more than 2 seconds.
0 to 9
Log No.
1
9
9
1
Previous or Next 0 to 9
Channel No.
To go to other slots To go to specific channel
/
A a
218 Installation Manual
2.10.5 Site Survey Using the KX-TCA255/KX-TCA256/KX-TCA355/KX-TD7590
