Panasonic KX-TDA600

b. Overlap the CS coverage areas of at least 2 CSs at any location in the installation site.
CS no. 1 CS no. 2
CS no. 3
CS no. 4
c. Make sure that the radio signal strength level is greater than "3" at any location in the service area
required by the user.
Referring to the Stored Scan Data
Using the KX-TD7684/KX-TD7694
1
9
9
1
NO.1
CS No.2 LEVEL: 9
NO.0
NOT SAVED
Press 1, 9, and POWER
for more than 2 seconds.
0 to 9
To the Desired Scan Data No.
Scan Data No.
Display example:
When there is scan data
When there is no scan data
Using the KX-TD7680
Press 1, 9, and POWER
for more than 2 seconds.
0 to 9
Scan Data No.
1
9
9
1
Display example:
When there is scan data
When there is no scan data
NO.1
CS No.2 LEVEL: 9
NO.0
NOT SAVED
To the Desired Scan Data No.
248 Installation Manual
2.11.5 Site Survey
