Panasonic KX-TDA600

Model No. Model Name Description
KX-TDA0189 8-Port Caller ID/Pay Tone Card
(CID/PAY8)
8-port Caller ID signal type FSK/FSK (with Call
Waiting Caller ID [Visual Caller ID])/DTMF, and
8-port
Pay
Tone
Service (12 kHz/16 kHz). To be
mounted on the ELCOT16 card.
KX-TDA0190 Optional 3-Slot Base Card (OPB3) Optional 3-slot base card for mounting a
maximum of 3 optional service cards from the
following: MSG4, ESVM2, ESVM4, DPH4,
DPH2 or EIO4 card.
KX-TDA0191 4-Channel Message Card (MSG4) 4-channel message card. To be mounted on the
OPB3 card.
KX-TDA0192 2-Channel Simplified Voice
Message Card (ESVM2)
2-channel simplified voice message card for
Built-in Simplified Voice Message feature. Also
supports
MSG card features. To be mounted on
the OPB3 card.
KX-TDA0193
8-Port Caller ID Card (CID8
) 8-port Caller ID signal type FSK/FSK (with Call
Waiting
Caller
ID
[Visual Caller ID])/DTMF. To be
mounted on the ELCOT16 card.
KX-TDA0194 4-Channel Simplified Voice
Message Card (ESVM4)
4-channel simplified voice message card for
Built-in Simplified Voice Message feature. Also
supports
MSG card features. To be mounted on
the OPB3 card.
KX-TDA0196
Remote Card (RMT) Analogue modem card for remote
communication with the PBX. ITU-T V.90
support. To be mounted on the EMPR card.
KX-TDA0284
4-Port BRI Card (BRI4) 4-port ISDN Basic Rate Interface card with 1
power failure transfer port. EURO-ISDN/ETSI
compliant.
KX-TDA0288 8-Port BRI Card (BRI8) 8-port ISDN Basic Rate Interface card with 1
power failure transfer port. EURO-ISDN/ETSI
compliant.
KX-TDA0290CE/
CJ
PRI Card (PRI30) 1-port ISDN Primary Rate Interface card (30B
channels). EURO-ISDN/ETSI compliant.
KX-TDA0290 PRI Card (PRI23) 1-port ISDN Primary Rate Interface card (23B
channels). NI (North American standard ISDN
protocol) compliant.
KX-TDA0410 CTI Link Card (CTI-LINK) Ethernet card for CTI communication via
10BASE-T port. CSTA Phase 3 protocol
compatible. To be installed in the Basic Shelf
only.
KX-TDA0470 16-Channel VoIP Extension Card
(IP-EXT16)
16-channel VoIP extension card. Compliant with
Panasonic proprietary protocol, and ITU-T G.
729a and G.711 CODEC methods.
KX-TDA0484 4-Channel VoIP Gateway Card
(IP-GW4E)
4-channel VoIP gateway card. Compliant with
VoIP H.323 V.2 protocol, and ITU-T G.729a, G.
723.1, and G.711 CODEC methods.
Installation Manual 31
1.3.1 Optional Equipment
