Panasonic KX-TDA600

LAN Connection via CTI-LINK Card
Switching Hub
To network port
RJ45
PC
Note
For pin assignments and maximum cabling distance, refer to "2.8.8 CTI-LINK Card (KX-TDA0410)".
External Modem Connection
3
2
20
6
RD (RXD)
SD (TXD)
ER (DTR)
DR (DSR)
2 RD (RXD)
3 SD (TXD)
4 ER (DTR)
6 DR (DSR)
To RS-232C port (25-pin)
To trunk/PBX extension
port assigned as the trunk destination
Modem
RS-232C Port
(9-pin)
External Modem (25-pin)
Signal Name Pin No. Pin No.
PBX (9-pin)
Signal Name
310 Installation Manual
3.2.1 PC Connection
