Panasonic KX-TDA600

2. Fix the metal bracket to the Basic Shelf with 4 screws (B).
TOP
Screw (B)
Metal Bracket
3. Lift
Expansion Shelf 1, attach it to the metal bracket on the Basic Shelf, and slide it backwards until it locks.
1
2
Metal Bracket
Installation Manual 55
2.2.5 Installation of Basic System or 2-shelf System (Floor Standing)
