Panasonic Lumix DC-S1 User Manual

6. Focus/Zoom
120
0 On the recording screen, you can rotate the focus ring to display the MF Assist
screen. If you have enlarged the picture by rotating the focus ring, the assist
screen will close approx. 10 seconds after the operation.
0 During MF, pressing [AF ON] will activate AF.
0 The recording distance reference mark is a mark
used to measure the focus distance.
Use this when taking pictures with MF or taking
close-up pictures.
0 Change the peaking sensitivity and the display method:
[] ¨ [ ] ¨ [Focus Peaking] (l 310)
0 Memorizes the MF Assist position separately for vertical and horizontal
orientations:
[] ¨ [ ] ¨ [Focus Switching for Vert / Hor] (l 116)
0 You can change the display method of the magnified screen:
[] ¨ [ ] ¨ [MF Assist] (l 330)
0 Change the MF Guide display method:
[] ¨ [ ] ¨ [MF Guide] (l 330)
0 Disable focus ring operation:
[] ¨ [ ] ¨ [Focus Ring Lock] (l 330)
0 Set the movement of the MF Assist position to loop:
[] ¨ [ ] ¨ [Looped Focus Frame] (l 333)
0 The camera memorizes the focus position when you turn it off:
[] ¨ [ ] ¨ [Lens Focus Resume] (l 348)
0 The amount of focus movement can be set:
[] ¨ [ ] ¨ [Focus Ring Control] (l 348)

Panasonic Lumix DC-S1 Specifications

General

Camera Type	Mirrorless
Sensor Type	CMOS
Resolution	24.2MP
Sensor Size	35.6 x 23.8 mm (Full-Frame)
Image Processor	Venus Engine
ISO Range	100-51200 (expandable to 50-204800)
Lens Mount	Leica L
Autofocus Points	225
Viewfinder Type	Electronic
Screen Size	3.2 inches
Screen Type	Tilting Touchscreen LCD
Battery	DMW-BLJ31
Weather Sealing	Yes
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	9 fps
Image Stabilization	5-axis sensor-shift image stabilization
Viewfinder Resolution	5.76 million dots
Screen Resolution	2.1 million dots
Video Resolution	4K UHD at 60p
Storage Media	SD/SDHC/SDXC (UHS-II compliant)
Connectivity	Wi-Fi, Bluetooth
Battery Life	400 shots (CIPA)
Dimensions	148.9 x 110.0 x 96.7 mm
Weight	1, 021 g (with battery and memory card)
