Panasonic Lumix DC-S1 User Manual

14. Menu Guide
309
[Focus] ¨ ¨
[AF Custom
Setting(Photo)]
`[Set 1]/[Set 2]/[Set 3]/[Set 4]
l 96
Select features of AF operation when recording
using [AFC] that are appropriate for the subject
and scene.
[AF Assist Light]
`[ON]/[OFF]
—
When recording in low light conditions, pressing
the shutter button halfway lights the AF assist
lamp, making it easier for the camera to focus.
0 The effective range of the AF assist lamp is
different depending on the lens used.
– When the interchangeable lens (S-R24105) is
attached and at Wide:
Approx. 1.0 m (3.3 feet) to 3.0 m (9.8 feet)
0 Remove the lens hood.
0 The AF assist lamp gets slightly blocked when
the interchangeable lens (S-R24105) is used,
but it does not affect the performance.
0 The AF assist lamp may be greatly blocked, and
it may become harder to focus when a lens with
large diameter is used.
0 When [Silent Mode] is being used, [AF Assist
Light] is fixed to [OFF].

Panasonic Lumix DC-S1 Specifications

General

Camera Type	Mirrorless
Sensor Type	CMOS
Resolution	24.2MP
Sensor Size	35.6 x 23.8 mm (Full-Frame)
Image Processor	Venus Engine
ISO Range	100-51200 (expandable to 50-204800)
Lens Mount	Leica L
Autofocus Points	225
Viewfinder Type	Electronic
Screen Size	3.2 inches
Screen Type	Tilting Touchscreen LCD
Battery	DMW-BLJ31
Weather Sealing	Yes
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	9 fps
Image Stabilization	5-axis sensor-shift image stabilization
Viewfinder Resolution	5.76 million dots
Screen Resolution	2.1 million dots
Video Resolution	4K UHD at 60p
Storage Media	SD/SDHC/SDXC (UHS-II compliant)
Connectivity	Wi-Fi, Bluetooth
Battery Life	400 shots (CIPA)
Dimensions	148.9 x 110.0 x 96.7 mm
Weight	1, 021 g (with battery and memory card)
