Panasonic Lumix DC-S1 User Manual

3. Basic Operations
64

Joystick (3421/)
The joystick can be operated in 8 directions by tilting it up, down, left, right
and diagonally and by pressing the center part.
0
When recording, this moves the AF area and MF
Assist.
The joystick functions for recording can be
changed in [Joystick Setting]. (l 337)

Touch Screen
Operations can be performed by touching the icons, slide bars, menus,
and other items displayed on the screen.
A Touch
Operation of touching and then lifting your
finger from the touch screen.
B Drag
Operation of moving a finger while it
touches the touch screen.
C Pinch (widen/narrow)
Operations of widening the distance
between two fingers (pinch out) and
narrowing the distance between two fingers
(pinch in) while they are touching the touch
screen.
A Tilt: Selects an item or numeric value, or
moves a position.
B Press: Confirms a setting.






Panasonic Lumix DC-S1 Specifications

General

Camera Type	Mirrorless
Sensor Type	CMOS
Resolution	24.2MP
Sensor Size	35.6 x 23.8 mm (Full-Frame)
Image Processor	Venus Engine
ISO Range	100-51200 (expandable to 50-204800)
Lens Mount	Leica L
Autofocus Points	225
Viewfinder Type	Electronic
Screen Size	3.2 inches
Screen Type	Tilting Touchscreen LCD
Battery	DMW-BLJ31
Weather Sealing	Yes
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	9 fps
Image Stabilization	5-axis sensor-shift image stabilization
Viewfinder Resolution	5.76 million dots
Screen Resolution	2.1 million dots
Video Resolution	4K UHD at 60p
Storage Media	SD/SDHC/SDXC (UHS-II compliant)
Connectivity	Wi-Fi, Bluetooth
Battery Life	400 shots (CIPA)
Dimensions	148.9 x 110.0 x 96.7 mm
Weight	1, 021 g (with battery and memory card)
