Panasonic Lumix S1H Series User Manual

10. Recording Videos
DVQX1961 (ENG)
118
[SS/Gain Operation]
You can switch the units of shutter speed values and gain (sensitivity)
values.
¨ [ ] ¨ [ ] ¨ Select [SS/Gain Operation]
[WFM/Vector Scope]
This displays the waveform monitor or the vector scope on the recording
screen. You can change the size of the waveform display.
1
Set the mode dial to [ ].
2
Set [WFM/Vector Scope].
≥ ¨ [ ] ¨ [ ] ¨ [WFM/Vector Scope]
Main Assist Functions
[SEC/ISO] Displays the shutter speed in seconds and the gain in ISO.
[ANGLE/ISO] Displays the shutter speed in degrees and the gain in ISO.
[SEC/dB]
Displays the shutter speed in seconds and the gain in dB.
0 0 dB corresponds to either of the following ISO sensitivity values.
– When [Dual Native Gain Setting] is set to [AUTO] or [LOW]:
[100]
– When [Dual Native Gain Setting] is set to [HIGH]: [640]
[WAVE] Displays a waveform.
[VECTOR] Displays the vector scope.
[OFF] —
DC-S1HGN-DVQX1961_eng.book 118 ページ ２０１９年８月８日 木曜日 午後５時５５分

Panasonic Lumix S1H Series Specifications

General

Sensor Type	CMOS
Resolution	24.2MP
Camera Type	Mirrorless
Shutter Speed	1/8000 to 60 sec, Bulb
Video Recording Format	MOV, MP4
Monitor Type	Tilting touchscreen LCD
Lens Mount	L-Mount
Dimensions	151 x 114 x 110 mm
ISO Sensitivity	ISO 100-51200 (expandable to ISO 50-204800)
Video Recording	6K/24p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
Viewfinder	5.76 million-dot OLED electronic viewfinder
LCD Screen	3.2-inch 2.33M-dot touchscreen
Autofocus System	Contrast Detection with 225-area DFD
Connectivity	Wi-Fi, Bluetooth, HDMI, USB-C
Battery Life	Approx. 400 shots (CIPA standard)
Sensor Size	35.6 x 23.8 mm
Continuous Shooting	Up to 9 fps
Memory Card Slots	Dual SD card slots (UHS-II)
Battery	DMW-BLJ31
Weight	Approx. 1052g (with battery and SD card)
Log Profiles	V-Log
Storage Media	SD/SDHC/SDXC
Weather Sealing	Yes, splash and dust resistant
