Panasonic Lumix S1H Series User Manual

12. Connections with External Devices (Video)
DVQX1961 (ENG)
147
You can record videos while monitoring their sound by connecting
commercially available headphones to the camera.
0
Do not use the headphone cables with the length of 3 m (9.8 feet) or more.
0 When headphones are connected, beep sounds, AF beep, and electronic shutter
sounds are muted.
0 While an XLR Microphone Adaptor is attached, [ ] is displayed on the
screen.
0 When [XLR Mic Adaptor Setting] is set to other than [OFF], the following
settings are fixed:
– [Sound Rec Level Limiter]: [OFF]
– [Wind Noise Canceller]: [OFF]
– [Sound Output]: [REC SOUND]
0 [Sound Rec Gain Level] and [Sound Rec Level Adj.] cannot be used when
[XLR Mic Adaptor Setting] is set to other than [OFF].
0 When the XLR Microphone Adaptor is attached, [Sound Rec Level Disp.]
automatically turns [ON], and the recording level is displayed on the screen.
0 When [Mute Sound Input] is set to [ON], the audio input from the XLR
Microphone Adaptor is muted.
0 If noises are recorded when using the AC adaptor, use the battery.
0 For details, refer to the operating instructions for the XLR Microphone
Adaptor.
Headphones
DC-S1HGN-DVQX1961_eng.book 147 ページ ２０１９年８月８日 木曜日 午後５時５５分

Panasonic Lumix S1H Series Specifications

General

Sensor Type	CMOS
Resolution	24.2MP
Camera Type	Mirrorless
Shutter Speed	1/8000 to 60 sec, Bulb
Video Recording Format	MOV, MP4
Monitor Type	Tilting touchscreen LCD
Lens Mount	L-Mount
Dimensions	151 x 114 x 110 mm
ISO Sensitivity	ISO 100-51200 (expandable to ISO 50-204800)
Video Recording	6K/24p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
Viewfinder	5.76 million-dot OLED electronic viewfinder
LCD Screen	3.2-inch 2.33M-dot touchscreen
Autofocus System	Contrast Detection with 225-area DFD
Connectivity	Wi-Fi, Bluetooth, HDMI, USB-C
Battery Life	Approx. 400 shots (CIPA standard)
Sensor Size	35.6 x 23.8 mm
Continuous Shooting	Up to 9 fps
Memory Card Slots	Dual SD card slots (UHS-II)
Battery	DMW-BLJ31
Weight	Approx. 1052g (with battery and SD card)
Log Profiles	V-Log
Storage Media	SD/SDHC/SDXC
Weather Sealing	Yes, splash and dust resistant
