Panasonic Lumix S1H Series User Manual

3. Basic Operations
DVQX1961 (ENG)
58
3
Adjust the focus.
≥Press the shutter button halfway.
≥Once the subject is in focus, the
focus indication lights.
(When the subject is not in focus,
the indication blinks.)
0
[ ] of the AF mode works and the AF area is displayed aligned to any
humans or animals.
4
Start recording.
≥Press the shutter button fully.
0 Backlight compensation operates automatically to prevent subjects from
appearing dark when there is a backlight.
0 Each press of [ ] changes the AF mode ([ ] ([Face/Eye/Body/Animal
Detect.])/[ ] ([Tracking])).
For information about AF modes, refer to page 65 and 66.
0 When recording using a flash, the camera switches to the appropriate flash
mode for the recording conditions.
Recording Using Touch Functions
0 With the default settings, the Touch Tab is not displayed.
Set [Touch Tab] to [ON] in [Touch Settings] in the [Custom] ([Operation])
menu. (l 165)
DC-S1HGN-DVQX1961_eng.book 58 ページ ２０１９年８月８日 木曜日 午後５時５５分

Panasonic Lumix S1H Series Specifications

General

Sensor Type	CMOS
Resolution	24.2MP
Camera Type	Mirrorless
Shutter Speed	1/8000 to 60 sec, Bulb
Video Recording Format	MOV, MP4
Monitor Type	Tilting touchscreen LCD
Lens Mount	L-Mount
Dimensions	151 x 114 x 110 mm
ISO Sensitivity	ISO 100-51200 (expandable to ISO 50-204800)
Video Recording	6K/24p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
Viewfinder	5.76 million-dot OLED electronic viewfinder
LCD Screen	3.2-inch 2.33M-dot touchscreen
Autofocus System	Contrast Detection with 225-area DFD
Connectivity	Wi-Fi, Bluetooth, HDMI, USB-C
Battery Life	Approx. 400 shots (CIPA standard)
Sensor Size	35.6 x 23.8 mm
Continuous Shooting	Up to 9 fps
Memory Card Slots	Dual SD card slots (UHS-II)
Battery	DMW-BLJ31
Weight	Approx. 1052g (with battery and SD card)
Log Profiles	V-Log
Storage Media	SD/SDHC/SDXC
Weather Sealing	Yes, splash and dust resistant
