Panasonic Lumix S1H Series User Manual

3. Basic Operations
DVQX1961 (ENG)
53
This screen allows you to view the current recording settings on the
monitor. You can also touch the screen to change the settings.
In the [ ] mode (Creative Video mode), the display changes to one
especially for video. (l 190)
1
Display the control panel.
≥Press [DISP.] several times.
2
Touch the items.
≥The setting screens for each of the
items are displayed.
3
Change the setting.
Example) Changing the AF mode
≥Touch the setting item.
4
Touch [Set].

Changing Directly Using the
Dial
Steps
2
to
4
can also be changed using the
following operations.
1
Press one of 3421 to enable
selection of items.
0
Selected items are displayed in yellow.
2
Press 3421 to select an item.
0
Selection is also possible by rotating
or .
3
Rotate to change the settings values.
Control Panel
0 Some items cannot be set depending on the recording mode or camera
settings.
999
999
AWB
Fn
ISO
AUTO
0 0
0
AFS FINE
3:2
AWB
AFS FINE
3:2
AWB
AFS FINE
3:2
DC-S1HGN-DVQX1961_eng.book 53 ページ ２０１９年８月８日 木曜日 午後５時５５分

Panasonic Lumix S1H Series Specifications

General

Sensor Type	CMOS
Resolution	24.2MP
Camera Type	Mirrorless
Shutter Speed	1/8000 to 60 sec, Bulb
Video Recording Format	MOV, MP4
Monitor Type	Tilting touchscreen LCD
Lens Mount	L-Mount
Dimensions	151 x 114 x 110 mm
ISO Sensitivity	ISO 100-51200 (expandable to ISO 50-204800)
Video Recording	6K/24p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
Viewfinder	5.76 million-dot OLED electronic viewfinder
LCD Screen	3.2-inch 2.33M-dot touchscreen
Autofocus System	Contrast Detection with 225-area DFD
Connectivity	Wi-Fi, Bluetooth, HDMI, USB-C
Battery Life	Approx. 400 shots (CIPA standard)
Sensor Size	35.6 x 23.8 mm
Continuous Shooting	Up to 9 fps
Memory Card Slots	Dual SD card slots (UHS-II)
Battery	DMW-BLJ31
Weight	Approx. 1052g (with battery and SD card)
Log Profiles	V-Log
Storage Media	SD/SDHC/SDXC
Weather Sealing	Yes, splash and dust resistant
