Panasonic Lumix S1H Series User Manual

2. Getting Started
DVQX1961 (ENG)
37
1
Set the camera on/off switch to [OFF].
2
Turn the lens rear cap and the body cap in the direction
of the arrow to remove them.
0 When removing the body cap, rotate it while pressing the lens release button
A.
3
Align the lens fitting marks B
on the lens and camera and
then rotate the lens in the
direction of the arrow.
≥Attach the lens by rotating it until it
clicks.
0
Insert the lens straight in.

Removing a Lens
1
Set the camera on/off switch to [OFF].
2
While pressing the lens release button
A, rotate the lens in the direction of the
arrow until it stops and then remove it.
0
After removing the lens, be sure to attach
the body cap and the lens rear cap.
Attaching a Lens
0 Change the lens in a location where there is not a lot of dirt and dust.
0 Change the lens while the lens cap is attached.





DC-S1HGN-DVQX1961_eng.book 37 ページ ２０１９年８月８日 木曜日 午後５時５５分

Panasonic Lumix S1H Series Specifications

General

Sensor Type	CMOS
Resolution	24.2MP
Camera Type	Mirrorless
Shutter Speed	1/8000 to 60 sec, Bulb
Video Recording Format	MOV, MP4
Monitor Type	Tilting touchscreen LCD
Lens Mount	L-Mount
Dimensions	151 x 114 x 110 mm
ISO Sensitivity	ISO 100-51200 (expandable to ISO 50-204800)
Video Recording	6K/24p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
Viewfinder	5.76 million-dot OLED electronic viewfinder
LCD Screen	3.2-inch 2.33M-dot touchscreen
Autofocus System	Contrast Detection with 225-area DFD
Connectivity	Wi-Fi, Bluetooth, HDMI, USB-C
Battery Life	Approx. 400 shots (CIPA standard)
Sensor Size	35.6 x 23.8 mm
Continuous Shooting	Up to 9 fps
Memory Card Slots	Dual SD card slots (UHS-II)
Battery	DMW-BLJ31
Weight	Approx. 1052g (with battery and SD card)
Log Profiles	V-Log
Storage Media	SD/SDHC/SDXC
Weather Sealing	Yes, splash and dust resistant
