Panasonic Lumix S1H Series User Manual

2. Getting Started
DVQX1961 (ENG)
38
The monitor on this camera has angling and tilting that you can adjust in
combinations to freely change the orientation and angle.
At the time of purchase, the monitor is stowed in the camera body. Turn the
monitor surface out before use.
1
Open the monitor.
2
Rotate the monitor.
0 You can rotate 180° towards the lens and
90° down.
3
Return the monitor to the
original position.
0 When you have attached a lens that does not have a communication function
with this camera, after turning on the camera, a message asking for
confirmation of the lens information is displayed. You can register items such
as the image circle and focal length for the lens when you select [Yes]. (l 75)
0 You can change the settings so that the confirmation message is not
displayed:
[] ¨ [ ] ¨ [Lens Info. Confirmation]
Adjusting the Monitor Direction and
Angle
180°
90°
180°
DC-S1HGN-DVQX1961_eng.book 38 ページ ２０１９年８月８日 木曜日 午後５時５５分

Panasonic Lumix S1H Series Specifications

General

Sensor Type	CMOS
Resolution	24.2MP
Camera Type	Mirrorless
Shutter Speed	1/8000 to 60 sec, Bulb
Video Recording Format	MOV, MP4
Monitor Type	Tilting touchscreen LCD
Lens Mount	L-Mount
Dimensions	151 x 114 x 110 mm
ISO Sensitivity	ISO 100-51200 (expandable to ISO 50-204800)
Video Recording	6K/24p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
Viewfinder	5.76 million-dot OLED electronic viewfinder
LCD Screen	3.2-inch 2.33M-dot touchscreen
Autofocus System	Contrast Detection with 225-area DFD
Connectivity	Wi-Fi, Bluetooth, HDMI, USB-C
Battery Life	Approx. 400 shots (CIPA standard)
Sensor Size	35.6 x 23.8 mm
Continuous Shooting	Up to 9 fps
Memory Card Slots	Dual SD card slots (UHS-II)
Battery	DMW-BLJ31
Weight	Approx. 1052g (with battery and SD card)
Log Profiles	V-Log
Storage Media	SD/SDHC/SDXC
Weather Sealing	Yes, splash and dust resistant
