2. Getting Started
DVQX1961 (ENG)
35
This camera supports the double card slot function. When two cards are
used, relay recording, backup recording, and allocation recording are
available.
For information about the cards that can be used, refer to page 16.
1
Open the card door.
≥Slide the card door in the direction
of the arrow while pushing down the
card door lock lever.
2
Insert the cards.
A Card slot 1
B Card slot 2
≥Match the orientation of the cards
as shown in the figure and then
insert them firmly until they click.
0
Do not touch the card connection
contacts C.
3
Close the card door.
≥Close the card door and slide it
firmly in the direction of the arrow
until it clicks.
0
The cards are displayed on the status
LCD.
Inserting Cards (Optional)
0 You can set the way to record to card slots 1 and 2.
[] ¨ [ ] ¨ [Double Card Slot Function] (l 61)







DC-S1HGN-DVQX1961_eng.book 35 ページ ２０１９年８月８日 木曜日 午後５時５５分

Panasonic Lumix S1H Series Specifications

General

Sensor Type	CMOS
Resolution	24.2MP
Camera Type	Mirrorless
Shutter Speed	1/8000 to 60 sec, Bulb
Video Recording Format	MOV, MP4
Monitor Type	Tilting touchscreen LCD
Lens Mount	L-Mount
Dimensions	151 x 114 x 110 mm
ISO Sensitivity	ISO 100-51200 (expandable to ISO 50-204800)
Video Recording	6K/24p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
Viewfinder	5.76 million-dot OLED electronic viewfinder
LCD Screen	3.2-inch 2.33M-dot touchscreen
Autofocus System	Contrast Detection with 225-area DFD
Connectivity	Wi-Fi, Bluetooth, HDMI, USB-C
Battery Life	Approx. 400 shots (CIPA standard)
Sensor Size	35.6 x 23.8 mm
Continuous Shooting	Up to 9 fps
Memory Card Slots	Dual SD card slots (UHS-II)
Battery	DMW-BLJ31
Weight	Approx. 1052g (with battery and SD card)
Log Profiles	V-Log
Storage Media	SD/SDHC/SDXC
Weather Sealing	Yes, splash and dust resistant
