Panasonic Lumix S1H Series User Manual

12. Connections with External Devices (Video)
DVQX1961 (ENG)
143
Outputting Down-converted Audio to an HDMI Device
When an XLR Microphone Adaptor (DMW-XLR1: optional) is attached,
audio is down-converted to a format suitable for the connected HDMI
external device before being output.
¨ [ ] ¨ [ ] ¨ [HDMI Rec Output] ¨ Select [Sound Down
Convert]
Outputting Audio via HDMI
Output audio to an external device connected by HDMI.
¨ [ ] ¨ [ ] ¨ [HDMI Rec Output] ¨ Select [Sound Output (HDMI)]
Settings: [ON]/[OFF]
With a Stereo Shotgun Microphone (DMW-MS2: optional) or Stereo
Microphone (VW-VMS10: optional), you can record higher-quality audio
compared to the built-in microphone.
[AUTO] Output is down-converted to match the connected device.
[OFF] Output is according to the settings in [XLR Mic Adaptor Setting].
External Microphones (Optional)
DC-S1HGN-DVQX1961_eng.book 143 ページ ２０１９年８月８日 木曜日 午後５時５５分

Panasonic Lumix S1H Series Specifications

General

Sensor Type	CMOS
Resolution	24.2MP
Camera Type	Mirrorless
Shutter Speed	1/8000 to 60 sec, Bulb
Video Recording Format	MOV, MP4
Monitor Type	Tilting touchscreen LCD
Lens Mount	L-Mount
Dimensions	151 x 114 x 110 mm
ISO Sensitivity	ISO 100-51200 (expandable to ISO 50-204800)
Video Recording	6K/24p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
Viewfinder	5.76 million-dot OLED electronic viewfinder
LCD Screen	3.2-inch 2.33M-dot touchscreen
Autofocus System	Contrast Detection with 225-area DFD
Connectivity	Wi-Fi, Bluetooth, HDMI, USB-C
Battery Life	Approx. 400 shots (CIPA standard)
Sensor Size	35.6 x 23.8 mm
Continuous Shooting	Up to 9 fps
Memory Card Slots	Dual SD card slots (UHS-II)
Battery	DMW-BLJ31
Weight	Approx. 1052g (with battery and SD card)
Log Profiles	V-Log
Storage Media	SD/SDHC/SDXC
Weather Sealing	Yes, splash and dust resistant
