Panasonic Lumix S1H Series User Manual

DVQX1961 (ENG)
87
9. Flash
This document gives an overview of recording with a flash. Refer to the
“Operating Instructions” (PDF format) for details about recording using a
flash and recording with a wireless flash.
Removing the Hot Shoe Cover
Before attaching the Flash (optional), remove the hot shoe cover.
Refer to the operating instructions for the Flash for details about how to
attach it.
Remove the hot shoe cover by
pulling it in the direction indicated
by arrow 2 while pressing it in the
direction indicated by arrow 1.

Flash Synchro Socket
You can use a commercially available external flash by connecting a
synchro cable to the flash synchro socket.
Using an External Flash (Optional)
0 Flash recording is not possible when the following functions are being used:
– [6K/4K PHOTO]/[Post-Focus]
– [ELEC.]/[Silent Mode]/[High Resolution Mode]
– [Filter Settings]
0 Use an external flash with a synchronisation voltage of 250 V or less.
0 In the [ ] mode, the flash synchro socket is used to synchronise time
codes with an external device. (l 108) Do not connect an external flash to the
flash synchro socket when set to the [ ] mode. Doing so may cause a
malfunction in the camera.


DC-S1HGN-DVQX1961_eng.book 87 ページ ２０１９年８月８日 木曜日 午後５時５５分

Panasonic Lumix S1H Series Specifications

General

Sensor Type	CMOS
Resolution	24.2MP
Camera Type	Mirrorless
Shutter Speed	1/8000 to 60 sec, Bulb
Video Recording Format	MOV, MP4
Monitor Type	Tilting touchscreen LCD
Lens Mount	L-Mount
Dimensions	151 x 114 x 110 mm
ISO Sensitivity	ISO 100-51200 (expandable to ISO 50-204800)
Video Recording	6K/24p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
Viewfinder	5.76 million-dot OLED electronic viewfinder
LCD Screen	3.2-inch 2.33M-dot touchscreen
Autofocus System	Contrast Detection with 225-area DFD
Connectivity	Wi-Fi, Bluetooth, HDMI, USB-C
Battery Life	Approx. 400 shots (CIPA standard)
Sensor Size	35.6 x 23.8 mm
Continuous Shooting	Up to 9 fps
Memory Card Slots	Dual SD card slots (UHS-II)
Battery	DMW-BLJ31
Weight	Approx. 1052g (with battery and SD card)
Log Profiles	V-Log
Storage Media	SD/SDHC/SDXC
Weather Sealing	Yes, splash and dust resistant
