Panasonic Lumix S1H Series User Manual

11. Special Video Recording
DVQX1961 (ENG)
130

Reading LUT Files
1
Insert a card on which LUT data is saved into the camera.
2
Select [Read LUT File].
0
¨ [ ] ¨ [ ] ¨ [V-Log View Assist] ¨ [Read LUT File] ¨ [Card Slot
1]/[Card Slot 2]
3
Press 34 to select the LUT data to read and then press or .
4
Press 34 to select the location to register the data, and then press
or .
0
When registered items are selected, they will be overwritten.
0 When applying the LUT data, [LUT] is displayed on the recording screen.
0 Up to 4 LUT data files can be registered.
0 The following LUT data can be used:
– The “.vlt” format, which meets the requirements specified in the “VARICAM
3DLUT REFERENCE MANUAL Rev.1.0”
– File names consisting of up to 8 alphanumeric characters (excluding
extension)
0 Save the LUT data with a file extension of “.vlt” in the root directory of the card
(the folder opened when the card is opened on a PC).
DC-S1HGN-DVQX1961_eng.book 130 ページ ２０１９年８月８日 木曜日 午後５時５５分

Panasonic Lumix S1H Series Specifications

General

Sensor Type	CMOS
Resolution	24.2MP
Camera Type	Mirrorless
Shutter Speed	1/8000 to 60 sec, Bulb
Video Recording Format	MOV, MP4
Monitor Type	Tilting touchscreen LCD
Lens Mount	L-Mount
Dimensions	151 x 114 x 110 mm
ISO Sensitivity	ISO 100-51200 (expandable to ISO 50-204800)
Video Recording	6K/24p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
Viewfinder	5.76 million-dot OLED electronic viewfinder
LCD Screen	3.2-inch 2.33M-dot touchscreen
Autofocus System	Contrast Detection with 225-area DFD
Connectivity	Wi-Fi, Bluetooth, HDMI, USB-C
Battery Life	Approx. 400 shots (CIPA standard)
Sensor Size	35.6 x 23.8 mm
Continuous Shooting	Up to 9 fps
Memory Card Slots	Dual SD card slots (UHS-II)
Battery	DMW-BLJ31
Weight	Approx. 1052g (with battery and SD card)
Log Profiles	V-Log
Storage Media	SD/SDHC/SDXC
Weather Sealing	Yes, splash and dust resistant
